KCD2-STC-1

产品大图

Product function

The K-system comprises signal conditioners for signal transfer between control system and safe area as well as isolated barriers for communication with field devices in hazardous areas. They are preferred for these kinds of mixed applications. Wide range of isolated barriers and signal conditioners for mixed applications. Modules for universal power supply. Reduced wiring by Power Rail. Removable terminals. Many modules with marine approvals and SIL assessment.

Product features

1-channel signal conditioner

24 V DC supply (Power Rail)

Input for 2-wire SMART transmitters and current sources

Output for 4 mA ~20 mA or 1 V ~5 V

Housing width 12.5 mm

Up to SIL 2 acc. to IEC/EN 61508

Housing width: 12.5 mm

HART communication

Safety Integrity Level (SIL): SIL 2

Rated voltage: 19~30 V DC

Field device: 2-wire transmitter

Input signal: 4~20 mA limited to approx. 26 mA

Application area

Industrial Automation
















KCD2-STC-1 Manual.pdf
